Available as single box + USB cable replacement
Usage & Benefits
The USB isolators effect a potential decoupling of all USB connections and separate the 'normal' PC system from the critical application.
Protection & security
They are the professional tools to avoid and fight ground loops and equalizing currents and to protect against overvoltage.
Certified quality
High isolating voltage and certification according to IEC60601-1 recommend the isolators also in sensitive applications.
Advanced Safety
The ISOUSB-PLUS Series
IFTOOLS continues to take the USB isolation to the next safety level.
The ISOUSB-PLUS isolator series provides you with:
- TÜV certification to the highest safety standard IEC 60601-1 Rev 3.2
- Isolation 7500 Vdc 1 second, 5000 Vrms 1 minute
- Robust shielded metal housing
- High retention force connectors (box)
Datasheet & Leaflet
The Box
Unique high up to 7.5 kV isolation for data and energy together with an unbeatable high working range recommend it for very sensitive and critical applications.
The Cable
Extra safe and easy usage. Just exchange the USB cable for the isolator cable — no further connections needed. Available with several connectors.
MORE FEATURES
Led indicators
(Multi) coloured LEDs display the state of the USB connection.
Ready to use
OS independent!
No software or driver needed.
Overload proof
Don't worry if something is going wrong.
3 year warranty
Made in Germany.
14 day sale or return.
Isolator Applications
Medical Appliances
Fitness Machines
Industry Robots
Production Equipment
Industry Controllers
Audio Ground Breaking
Good to knowCertified against EN60601-1 Rev. 3.2 means the highest quality standards and reliability through selected components and best possible design. You should not expect less! |
Medial & FitnessWhenever a human is connected to a PC for medical or monitoring reasons you must take precautions that the person must never suffer harm due to possible or accidental defects. Safety first always applies! |
Industry & sensitive applicationsTo protect control systems and PCs against power surge, voltage burst and ground loops caused by connected USB devices working in harsh environments. |
Makers & DevelopersFor all people who develop, test or simply work with USB devices and want to avoid to damage their USB hub or, even worse, their PC just by accident. |
Audio & Sound studiosFighting buzzing and other unwanted noises coupled by connected Audio/Midi devices with own power supply forming a ground loop. The isolator Full Speed 12Mbps is sufficient for sample rates up to 96kHz/24bit. |
And just in case...Do not take any risk when you need to connect a used and possibly defective USB device with your irreplaceable PC. Especially in the service area. Always play it safe with the ISOUSB-PLUS isolator. |
Specifications
| ISOUSB-PLUS | |
|---|---|
| Transmission rates | USB 1.1/2.0 compatible, full speed (12Mbit/s) |
| Isolation | 7500 Vdc 1sec, 5000 Vrms 1 min, max. working range 250 Vrms |
| Transient protection | ±15 kV according to IEC 61000-4-2 |
| Certification | IEC60601-1:2020 (Ed3.2), IEC60601-1-2:2015, CE, FCC, JIS T 0601-1:2017 (IEC 60601-1:2005 + A1:2012 + A2:2020) |
| Energy transfer | Primary to secondary side max. 3W, efficiency about 85%, overload proof |
| Auxiliary voltage input | no |
| Design | Robust shielded metal housing with USB ports (box) or cable connectors (cable) |
| Connectors Box | High retention force connectors, USB-Prim: Jack Type B, USB-Sec: Jack Type A |
| Connectors Cable | Primary: USB Plug Type A, Secondary: USB Plug Type B |
| Environment | 0-40°C (32-113°F) 20-90% humidity, non-condensing. |
| Dimension & Weight | 96mm x 57mm x 18mm (length, width, height). Weight ca. 110g box, 220g cable |
| Scope of delivery | Isolator, USB cable 2m with A and B plug connectors (only box version), detailed manual |
| Price | 189 € without Tax |
| Available as | |
| Shop ISOUSB-PLUS-BOX PDF | |
|---|---|
|
Sec: Std-A Socket
|
Prim: Std-B Socket
|
|
What type fits you best?
- Highest safety standard
- Low costs
- Universal usage
- Easy connectable
All specs on a glance
Just download our comparison paper with all isolator specifications as a PDF file.
